1.S型雙吸中開泵與SH型泵的區別：相同點
1.都為雙吸中開泵：?jiǎn)渭夒p吸水平中開清水離心泵
2.輸送介質相同：輸送清水或物理化學性質類似于清水的液體,液體的最高溫度不得超過80℃。
3.適用場景相同：適用于于工廠循環水泵、洗煤循環水泵、城市給排水、電站、大型水利、農田灌溉和排澇等。
4.S型泵可替代SH型泵：瀟湘制泵生產的S型泵可替代SH型泵的型號參數。
2.S型雙吸中開泵與SH型泵的區別：不同點
Sh型中開泵從電機驅動端看，逆時針旋轉，即吸入口在左，吐出口在右。
S型雙吸泵從電機驅動端看，順時針旋轉，即吸入口在右，吐出口在左。
3.湖南瀟湘制泵生產的S型雙吸中開泵替代SH型泵型號對照表
| 單級雙吸中開清水離心泵 | |||
| S型雙吸中開泵 | 同性能SH型泵 | S型雙吸中開泵 | 同性能SH型泵 |
| 150S50 | 6Sh-9 | 350S26 | 14Sh-19 |
| 150S50A | 6Sh-9A | 350S26A | 14Sh-19A |
| 150S50B | 6Sh-9B | 350S44 | 14Sh-13 |
| 150S78 | 6Sh-6 | 350S44A | 14Sh-13A |
| 150S78A | 6Sh-6A | 350S75 | 14Sh-9 |
| 150S78B | 6Sh-6B | 350S75A | 14Sh-9A |
| 200S42 | 8Sh-13 | 350S75B | 14Sh-9B |
| 200S42A | 8Sh-13A | 350S125 | 14Sh-6 |
| 200S63 | 8Sh-9 | 350S125A | 14Sh-6A |
| 200S63A | 8Sh-9A | 350S125B | 14Sh-6B |
| 200S95 | 8Sh-6 | 500S13 | 20Sh-28 |
| 200S95A | 8Sh-6A | 500S22 | 20Sh-19 |
| 200S95B | 8Sh-6B | 500S22A | 20Sh-19A |
| 250S14 | 10Sh-19 | 500S35 | 20Sh-13 |
| 250S14A | 10Sh-19A | 500S35A | 20Sh-13A |
| 250S24 | 10Sh-13 | 500S59 | 20Sh-9 |
| 250S24A | 10Sh-13A | 500S59A | 20Sh-9A |
| 250S39 | 10Sh-9 | 500S59B | 20Sh-9B |
| 250S39A | 10Sh-9A | 500S98 | 20Sh-6 |
| 250S65 | 10Sh-6 | 500S98A | 20Sh-6A |
| 250S65A | 10Sh-6A | 500S98B | 20Sh-6B |
| 300S12 | 12Sh-28 | 600S32 | 24Sh-19 |
| 300S12A | 12Sh-28A | 600S32A | 24Sh-19A |
| 300S19 | 12Sh-19 | 600S47 | 24Sh-13 |
| 300S19A | 12Sh-19A | 600S75 | 24Sh-9 |
| 300S32 | 12Sh-13 | 600S75A | 24Sh-9A |
| 300S32A | 12Sh-13A | 700S92 | 28Sh-10 |
| 300S58 | 12Sh-9 | 700S47 | 28Sh-12 |
| 300S58A | 12Sh-9A | 800S22 | 32Sh-24 |
| 300S58B | 12Sh-9B | 800S22A | 32Sh-24A |
| 300S90 | 12Sh-6 | 800S32 | 32Sh-19 |
| 300S90A | 12Sh-6A | 800S76 | 32Sh-10 |
| 300S90B | 12Sh-6B | 800S76J | 32Sh-10J |
| 350S16 | 14Sh-28 | 1200S22 | 48Sh-22 |
| 350S16A | 14Sh-28A | 1200S22A | 48Sh-22A |
本文關于S型雙吸中開泵與SH型泵的區別，湘泵S型泵替代SH型泵型號對照表等內容均由中開泵生產廠家：湖南瀟湘制泵整理發布。
